YMLED-6411 Multi-spec Aluminum LED Street Light

The YMLED-6411 is a multi-specification aluminum LED street light designed specifically for outdoor lighting, offering flexible size options. It features high-quality LED chips such as Philips 5050, CREE XTE, CREE XPG, or Ledstar 5050, providing a selectable CRI of 70 or 80, and a color temperature range from 2200K to 6500K to meet various lighting needs.

The lamp body is made of die-cast aluminum (6063-T5), supports RAL color card customization, and is equipped with an anti-UV polyester powder coating.  Optional corrosion-resistant treatment exceeding 1000 hours of salt spray testing is available. The power supply is compatible with AC 100-277Vac, 50/60Hz, and has a lifespan of over 50,000 hours at 25°C.

It boasts an IP65 dustproof and waterproof rating and IK08 impact resistance, with an operating temperature range of -30°C to +50°C. Optional features include 10kV overvoltage protection, DALI/0-10V/PWM/4Di dimming interfaces, and 5-7 pin NEMA/Zhaga connectors and sensor integration. Depending on the specifications, the net weight is 9/8 kg, 9.5/8.5 kg, and 13/11.8 kg, making it a reliable choice for street and plaza lighting.

CRI Colour Rendering Index: 70,80(Optional)
LED Chips: Philips5050, CREE XTE, CREE XPG, Ledstar 5050 (selectable)
CCT: 2200K-6500K
RAL finish on request; anti-UV polyester powder coating surface, salt spray resistance over 1,000 hours (optional)
Body Material: Die-cast aluminium,6063-T5
Power supply: AC 100-277 Vac; 50/60 Hz.
Useful life >  50,000h (Ta= 25°C)
Waterproof Protection & Impact Protection Rating: IP65/IK08
Overvoltage protection: 10kV (optional)
Operating temperature: -30°C to +50°C.
Net weight: 9/8(kgs), 9.5/8.5(kgs), 13/11.8(kgs)
Available options: DALI, 0-10V, PWM,  4Di.
Optional: 5- to 7-pin NEMA connector, Zhaga, and sensors

Product Code Rated Power LED Qty Luminous Flux G.W/N.W Packing Size
YMLED-6411S 30W 32 3960 9/8(kgs) 800X180X95mm
YMLED-6411S 60W 32 7920 9/8(kgs) 800X180X95mm
YMLED-6411M 70W 32 9240 9.5/8.5(kgs) 955X180X95mm
YMLED-6411M 90W 32 11880 9.5/8.5(kgs) 955X180X95mm
YMLED-6411L 120W 64 15840 13/11.8(kgs) 1275X180X95mm
YMLED-6411L 150W 64 19800 13/11.8(kgs) 1275X180X95mm
YMLED-6411L 180W 64 23760 13/11.8(kgs) 1275X180X95mm
Material: PC
Angle: TYPE2
Chip: 5050 3030×4 7070
Size: 50×50
Order Code: 3292
Material: PC
Angle: TYPE3
Chip: 5050 3030×4 7070
Size: 50×50
Order Code: 3293
Material: PC
Angle: TYPE4
Chip: 5050 3030×4 7070
Size: 50×50
Order Code: 3294
Material: PC
Angle: TYPE5
Chip: 5050 3030×4 7070
Size: 50×50
Order Code: 3295
Material: PC
Angle: 100×160
Chip: 5050 3030×4 7070
Size: 50×50
Order Code: 2581
  • IP65 IK08 Suitable for outdoor installation, with maximum impact resistance
  • DALI-2  Dimmable version available
  • RAL finish on request
