The YMLED-6311 is a custom-designed LED pathway light featuring a new design. Its modern, streamlined appearance, combined with an aluminum body, ensures both structural strength and aesthetic quality. The luminaire offers high color rendering and multiple color temperature options, providing excellent and comfortable lighting.
Using internationally renowned LED chips, the light source is long-lasting and stable, with a lifespan exceeding 50,000 hours. It boasts a high protection rating of IP65/IK08 and a wide operating temperature range, making it suitable for various outdoor environments. It supports multiple intelligent control protocols and can be customized in terms of appearance and functionality to meet individual project requirements.
It is ideal for pedestrian areas requiring high-quality landscape lighting, such as urban parks and greenways, waterfront promenades, high-end residential communities, and university campuses.
CRI Colour Rendering Index: 70,80(Optional)
LED Chips: Philips5050、CREE XTE、CREE XPG、Ledstar 5050 (selectable)
CCT: 2200K-6500K
RAL finish on request; anti-UV polyester powder coating surface, salt spray resistance over 1,000 hours (optional)
Body Material: Die-cast aluminium,6063-T5
Power supply: AC 100-277 Vac; 50/60 Hz.
Useful life > 50,000h (Ta= 25°C)
Waterproof Protection & Impact Protection Rating: IP65/IK08
Overvoltage protection: 10kV (optional)
Operating temperature: -30°C to +50°C.
Net weight: 28/26(kgs)
Available options: DALI, 0-10V, PWM, 4Di.
Optional: 5- to 7-pin NEMA connector, Zhaga, and sensors
| Product Code | Rated Power | LED Qty | Luminous Flux | G.W/N.W | Packing Size |
| YMLED-6311 | 38W | 32 | 5016 | 28/26(kgs) | 175x95x650mm 175x95x4450mm |
| YMLED-6311 | 55W | 32 | 7150 | ||
| YMLED-6311 | 75W | 32 | 9600 |
![]() |
![]() |
![]() |
| Material: PC
Angle: TYPE2
Chip: 5050 3030×4 7070
Size: 50×50
Order Code: 3292
|
Material: PC
Angle: TYPE3
Chip: 5050 3030×4 7070
Size: 50×50
Order Code: 3293
|
Material: PC
Angle: TYPE4
Chip: 5050 3030×4 7070
Size: 50×50
Order Code: 3294
|
![]() |
![]() |
|
| Material: PC
Angle: TYPE5
Chip: 5050 3030×4 7070
Size: 50×50
Order Code: 3295
|
Material: PC
Angle: 100×160
Chip: 5050 3030×4 7070
Size: 50×50
Order Code: 2581
|
RAL and Height finish on request

Samples: Typically 7 working days.
Bulk Orders: Approximately 14-21 working days after receiving the deposit and confirming all specifications.
We accept payments in USD via T/T. The standard terms are:
30% deposit before production, 70% balance before shipment.
For orders below $1000 USD, full payment (100%) is required via T/T.
Our quotations are typically based on EXW or FOB trade terms.
Yes, we offer professional OEM/ODM customization services to meet specific requirements in product design, performance, and packaging.
With extensive experience in non-standard customized products, our engineering team is able to provide technical solutions and initial feedback within 12 hours.
Standard packaging includes brown outer cartons and brown inner boxes.
For orders of any quantity, we offer customization services, including: Laser-engraved logos on the lamp body. Custom-designed color boxes and cartons with your logo.
Considering that most of our customers are involved in engineering projects, we don't have an MOQ.
Our products comply with international standards, with CE and RoHS certifications for all categories. Some of the garden lights and street lamps also have ETL and ENEC certifications.
