YMLED-6307 Die-casing Aluminum High Power Garden Bollard Lights

The YMLED-6307 is a high-power LED bollard light specifically designed for courtyards, walkways, and plaza edges.  Its minimalist, slender columnar design blends seamlessly into the landscape, providing a soft and even ground-level lighting experience.
The lamp body is made of 6063-T5 die-cast aluminum, coated with a UV-resistant polyester powder coating, and supports RAL color customization.  Optional anti-corrosion treatment exceeding 1000 hours of salt spray resistance is available. With an IP65/IK08 protection rating, it can operate stably for extended periods in complex outdoor environments, including rain, snow, dust, and physical impact.
The light source supports high-quality LEDs such as Philips 5050 and CREE XTE/XPG, with adjustable color temperatures from 2200K to 6500K and a selectable color rendering index of 70/80. This allows for both creating a warm walkway atmosphere and meeting high-brightness lighting requirements. The wide voltage design is compatible with power grids in most regions worldwide, and the lifespan exceeds 50,000 hours at 25℃. Optional 10kV overvoltage protection is also available, significantly reducing maintenance costs.
The luminaire offers DALI, 0-10V, and PWM dimming protocols, as well as expansion options such as NEMA connectors, Zhaga interfaces, and sensors, meeting the needs of smart lighting upgrades and making it an ideal choice for creating immersive outdoor nightscapes.

CRI Colour Rendering Index: 70,80(Optional)
LED Chips: Philips5050, CREE XTE, CREE XPG, Ledstar 5050 (selectable)
CCT: 2200K-6500K
RAL finish on request; anti-UV polyester powder coating surface, salt spray resistance over 1,000 hours (optional)
Body Material: Die-cast aluminium,6063-T5
Power supply: AC 100-277 Vac; 50/60 Hz.
Useful life >  50,000h (Ta= 25°C)
Waterproof Protection & Impact Protection Rating: IP65/IK08
Overvoltage protection: 10kV (optional)
Operating temperature:  -30°C to +50°C.
Available options: DALI, 0-10V, PWM,  4Di.
Optional: 5- to 7-pin NEMA connector, Zhaga, and sensors

Protection grade:

IP65

Corrosion-proof capability:

II

Working condition:

-35℃ +45℃

Isolation class:

1

Power voltage:

170-220V 50-60Hz

High:

2.8m

Max power:

30W

Material: PC
Angle: TYPE2
Chip: 5050 3030×4 7070
Size: 50×50
Order Code: 3292
Material: PC
Angle: TYPE3
Chip: 5050 3030×4 7070
Size: 50×50
Order Code: 3293
Material: PC
Angle: TYPE4
Chip: 5050 3030×4 7070
Size: 50×50
Order Code: 3294
Material: PC
Angle: TYPE5
Chip: 5050 3030×4 7070
Size: 50×50
Order Code: 3295
Material: PC
Angle: 100×160
Chip: 5050 3030×4 7070
Size: 50×50
Order Code: 2581
  • IP65 IK08Suitable for outdoor installation, with maximum impact resistance
  • DALI-2  Dimmable version available
  • RAL and Height finish on request
