YMLED-6804 Integrated Solar Panel Aluminum Outdoor Street Lights

The YMLED-6804 integrated solar LED street light features a highly integrated design: the top-mounted, angled monocrystalline silicon solar panel seamlessly connects with the rectangular LED light module below, creating a fluid geometric silhouette. The overall housing is made of dark gray die-cast aluminum with a fine matte finish.  The dense heat dissipation fins at the bottom of the light body enhance cooling efficiency while adding industrial design details to the minimalist form.
This luminaire combines efficient energy harvesting with professional lighting functions. The solar panel utilizes high-conversion-rate monocrystalline silicon technology, coupled with an intelligent light control and energy management system, to achieve automatic power switching between day and night. The light body strictly adheres to outdoor protection standards, using 6063-T5 die-cast aluminum with an anti-UV powder coating. Optional RAL custom colors and enhanced salt spray protection (>1000 hours) are available. IP65 dustproof and waterproof rating and IK08 impact resistance ensure stable operation in various weather conditions. It is equipped with high-efficiency LED modules from multiple brands (Philips, CREE, etc. chips are optional), providing uniform road lighting through professional light distribution.  It supports 2200K-6500K color temperature adjustment and 70/80 high color rendering index options. In addition to solar power, the product also retains a traditional power grid interface (AC 100-277V) and intelligent control compatibility (DALI/0-10V/PWM/4Di), and optional NEMA/Zhaga interfaces and sensor modules are available to meet hybrid power supply and intelligent management needs.

CRI Colour Rendering Index: 70,80(Optional)
LED Chips: Philips5050, CREE XTE, CREE XPG, Ledstar 5050 (selectable)
CCT: 2200K-6500K
RAL finish on request; anti-UV polyester powder coating surface, salt spray resistance over 1,000 hours (optional)
Body Material: Die-cast aluminium,6063-T5
Power supply: AC 100-277 Vac; 50/60 Hz.
Useful life >  50,000h (Ta= 25°C)
Waterproof Protection & Impact Protection Rating: IP65/IK08
Overvoltage protection: 10kV (optional)
Operating temperature: -30°C to +50°C.
Net weight: 5/6.5(kgs)
Available options: DALI, 0-10V, PWM,  4Di.
Optional: 5- to 7-pin NEMA connector, Zhaga, and sensors

Solar panel Battery CCT Charging time IP Rating Working condition G.W/N.W Packing Size
5V/20W 3.2V/20AH 3000K/6500K 3~5h IP65 -20℃ / 50℃ 5/6.5(kgs) 495x495x450mm
Material: PC
Angle: TYPE2
Chip: 5050 3030×4 7070
Size: 50×50
Order Code: 3292
Material: PC
Angle: TYPE3
Chip: 5050 3030×4 7070
Size: 50×50
Order Code: 3293
Material: PC
Angle: TYPE4
Chip: 5050 3030×4 7070
Size: 50×50
Order Code: 3294
Material: PC
Angle: TYPE5
Chip: 5050 3030×4 7070
Size: 50×50
Order Code: 3295
Material: PC
Angle: 100×160
Chip: 5050 3030×4 7070
Size: 50×50
Order Code: 2581
  • IP65 IK08 Suitable for outdoor installation, with maximum impact resistance
  • DALI-2  Dimmable version available
  • RAL finish on request
