The YMLED-6212 is a low-profile LED in-ground light specifically designed for lawns and landscaped areas, providing soft yet effective functional lighting for outdoor landscapes with its unobtrusive installation.
The fixture features a one-piece die-cast aluminum alloy housing, offering a compact and robust structure with excellent UV resistance and corrosion resistance. Multiple light source options are available, including high-efficiency Philips 3030/2835 LEDs, CREE COB integrated modules, or traditional E27 sockets, meeting the configuration needs of different projects.
The optical system supports color temperature adjustment from 2200K to 6500K, with a color rendering index (CRI) of up to 80Ra, enhancing the natural colors of plants at night while ensuring safety for pathways. The entire product line meets IP65 dustproof and waterproof standards and IK08 impact resistance standards, capable of withstanding prolonged foot traffic and sprinkler systems. The operating temperature range is -30℃ to 50℃.
It supports universal wide voltage input (AC 100-277V) and is available in three lengths: 600mm, 800mm, and 1000mm, suitable for various landscape applications such as lawn boundary lighting, pathway guidance, and shrub accent lighting. Optional DALI intelligent dimming functionality is available for integrated control with the overall lighting system.
CRI Colour Rendering Index: 70,80(Optional)
LED Chips: Philips3030、Philips2835、CREE COB、E27
CCT: 2200K-6500K
RAL finish on request; anti-UV polyester powder coating surface, salt spray resistance over 1,000 hours (optional)
Body Material: Die-cast aluminium,6063-T5
Power supply: AC 100-277 Vac; 50/60 Hz.
Useful life > 50,000h (Ta= 25°C)
Waterproof Protection & Impact Protection Rating: IP65/IK08
Net weight: 600mm 4.5KG/800mm 5KG/1000mm 5.5KG
Operating temperature: -30°C to +50°C.
Available options: DALI, ON/OFF
| Protection grade | Corrosion-proof capability | Working condition | Isolation class | Power voltage | Max power |
| IP65 | Class II | -35℃ ~ +45℃ | Class I | 220V(±10%)/50Hz | 15W(E27) |
RAL and Height finish on request

Samples: Typically 7 working days.
Bulk Orders: Approximately 14-21 working days after receiving the deposit and confirming all specifications.
We accept payments in USD via T/T. The standard terms are:
30% deposit before production, 70% balance before shipment.
For orders below $1000 USD, full payment (100%) is required via T/T.
Our quotations are typically based on EXW or FOB trade terms.
Yes, we offer professional OEM/ODM customization services to meet specific requirements in product design, performance, and packaging.
With extensive experience in non-standard customized products, our engineering team is able to provide technical solutions and initial feedback within 12 hours.
Standard packaging includes brown outer cartons and brown inner boxes.
For orders of any quantity, we offer customization services, including: Laser-engraved logos on the lamp body. Custom-designed color boxes and cartons with your logo.
Considering that most of our customers are involved in engineering projects, we don't have an MOQ.
Our products comply with international standards, with CE and RoHS certifications for all categories. Some of the garden lights and street lamps also have ETL and ENEC certifications.
