The YMLED-6125 classic European-style aluminum alloy post-top light features an elegant three-tiered design. It boasts a crown-shaped decorative top, a white frosted PC lampshade in the middle, and a black die-cast aluminum base. The overall design is sleek and highly decorative. The lampshade's rounded and full profile evenly diffuses light, creating a soft, ambient glow at night. The classic contrast of black and white gives the fixture a timeless visual appeal.
This luminaire uses high-grade 6063-T5 die-cast aluminum material, with a surface treated with UV-resistant polyester powder coating. Optional RAL custom colors and enhanced salt spray protection (>1000 hours) are available. IP65 dustproof and waterproof rating and IK08 impact resistance ensure its durability and stability in outdoor environments. It supports various high-efficiency LED chips (Philips, CREE, etc.), offering a color temperature range of 2200K-6500K and high color rendering index (CRI 70/80) options to meet different lighting needs. Full voltage input (AC 100-277V) and smart control compatibility (DALI/0-10V/PWM/4Di) make it suitable for most regions worldwide. Optional standardized interfaces (NEMA/Zhaga) and sensor modules allow for integration into modern smart lighting systems.
CRI Colour Rendering Index: 70,80(Optional)
LED Chips: Philips 5050, CREE XTE, CREE XPG, Ledstar 5050, E27
CCT: 2200K-6500K
Body Material: Die-cast aluminium,6063-T5
RAL finish on request; anti-UV polyester powder coating surface, salt spray resistance over 1,000 hours (optional)
Power supply: AC 100-277 Vac; 50/60 Hz.
Useful life > 50,000h (Ta= 25°C)
Waterproof Protection & Impact Protection Rating: IP65/IK08
Overvoltage protection: 10kV (optional)
Operating temperature: -30°C to +50°C
Net weight: 10.4/12(kgs)
Available options: DALI, 0-10V, PWM, 4Di.
Optional: 5- to 7-pin NEMA connector, Zhaga, and sensors
| Product Code | Rated Power | LED Qty | Luminous Flux | G.W/N.W | Packing Size | Loading Qty |
| YMLED-6125(16) | 30W | 16 | 3150 | 10.4/12(kgs) | 490x490x905mm | 88PCS/20'GP 240PCS/40'HQ |
| YMLED-6125(20) | 40W | 20 | 4200 | 10.4/12(kgs) | 490x490x905mm | |
| YMLED-6125(24) | 55W | 24 | 5775 | 10.4/12(kgs) | 490x490x905mm | |
![]() |
![]() |
![]() |
| Material: PC
Angle: TYPE2
Chip: 5050 3030×4 7070
Size: 50×50
Order Code: 3292
|
Material: PC
Angle: TYPE3
Chip: 5050 3030×4 7070
Size: 50×50
Order Code: 3293
|
Material: PC
Angle: TYPE4
Chip: 5050 3030×4 7070
Size: 50×50
Order Code: 3294
|
![]() |
![]() |
|
| Material: PC
Angle: TYPE5
Chip: 5050 3030×4 7070
Size: 50×50
Order Code: 3295
|
Material: PC
Angle: 100×160
Chip: 5050 3030×4 7070
Size: 50×50
Order Code: 2581
|
RAL finish on request
Samples: Typically 7 working days.
Bulk Orders: Approximately 14-21 working days after receiving the deposit and confirming all specifications.
We accept payments in USD via T/T. The standard terms are:
30% deposit before production, 70% balance before shipment.
For orders below $1000 USD, full payment (100%) is required via T/T.
Our quotations are typically based on EXW or FOB trade terms.
Yes, we offer professional OEM/ODM customization services to meet specific requirements in product design, performance, and packaging.
With extensive experience in non-standard customized products, our engineering team is able to provide technical solutions and initial feedback within 12 hours.
Standard packaging includes brown outer cartons and brown inner boxes.
For orders of any quantity, we offer customization services, including: Laser-engraved logos on the lamp body. Custom-designed color boxes and cartons with your logo.
Considering that most of our customers are involved in engineering projects, we don't have an MOQ.
Our products comply with international standards, with CE and RoHS certifications for all categories. Some of the garden lights and street lamps also have ETL and ENEC certifications.
