The YMLED-6307 is a high-power LED bollard light specifically designed for courtyards, walkways, and plaza edges. Its minimalist, slender columnar design blends seamlessly into the landscape, providing a soft and even ground-level lighting experience.
The lamp body is made of 6063-T5 die-cast aluminum, coated with a UV-resistant polyester powder coating, and supports RAL color customization. Optional anti-corrosion treatment exceeding 1000 hours of salt spray resistance is available. With an IP65/IK08 protection rating, it can operate stably for extended periods in complex outdoor environments, including rain, snow, dust, and physical impact.
The light source supports high-quality LEDs such as Philips 5050 and CREE XTE/XPG, with adjustable color temperatures from 2200K to 6500K and a selectable color rendering index of 70/80. This allows for both creating a warm walkway atmosphere and meeting high-brightness lighting requirements. The wide voltage design is compatible with power grids in most regions worldwide, and the lifespan exceeds 50,000 hours at 25℃. Optional 10kV overvoltage protection is also available, significantly reducing maintenance costs.
The luminaire offers DALI, 0-10V, and PWM dimming protocols, as well as expansion options such as NEMA connectors, Zhaga interfaces, and sensors, meeting the needs of smart lighting upgrades and making it an ideal choice for creating immersive outdoor nightscapes.
CRI Colour Rendering Index: 70,80(Optional)
LED Chips: Philips5050, CREE XTE, CREE XPG, Ledstar 5050 (selectable)
CCT: 2200K-6500K
RAL finish on request; anti-UV polyester powder coating surface, salt spray resistance over 1,000 hours (optional)
Body Material: Die-cast aluminium,6063-T5
Power supply: AC 100-277 Vac; 50/60 Hz.
Useful life > 50,000h (Ta= 25°C)
Waterproof Protection & Impact Protection Rating: IP65/IK08
Overvoltage protection: 10kV (optional)
Operating temperature: -30°C to +50°C.
Available options: DALI, 0-10V, PWM, 4Di.
Optional: 5- to 7-pin NEMA connector, Zhaga, and sensors
|
Protection grade: |
IP65 |
|
Corrosion-proof capability: |
II |
|
Working condition: |
-35℃ +45℃ |
|
Isolation class: |
1 |
|
Power voltage: |
170-220V 50-60Hz |
|
High: |
2.8m |
|
Max power: |
30W |
![]() |
![]() |
![]() |
| Material: PC
Angle: TYPE2
Chip: 5050 3030×4 7070
Size: 50×50
Order Code: 3292
|
Material: PC
Angle: TYPE3
Chip: 5050 3030×4 7070
Size: 50×50
Order Code: 3293
|
Material: PC
Angle: TYPE4
Chip: 5050 3030×4 7070
Size: 50×50
Order Code: 3294
|
![]() |
![]() |
|
| Material: PC
Angle: TYPE5
Chip: 5050 3030×4 7070
Size: 50×50
Order Code: 3295
|
Material: PC
Angle: 100×160
Chip: 5050 3030×4 7070
Size: 50×50
Order Code: 2581
|
RAL and Height finish on request

Samples: Typically 7 working days.
Bulk Orders: Approximately 14-21 working days after receiving the deposit and confirming all specifications.
We accept payments in USD via T/T. The standard terms are:
30% deposit before production, 70% balance before shipment.
For orders below $1000 USD, full payment (100%) is required via T/T.
Our quotations are typically based on EXW or FOB trade terms.
Yes, we offer professional OEM/ODM customization services to meet specific requirements in product design, performance, and packaging.
With extensive experience in non-standard customized products, our engineering team is able to provide technical solutions and initial feedback within 12 hours.
Standard packaging includes brown outer cartons and brown inner boxes.
For orders of any quantity, we offer customization services, including: Laser-engraved logos on the lamp body. Custom-designed color boxes and cartons with your logo.
Considering that most of our customers are involved in engineering projects, we don't have an MOQ.
Our products comply with international standards, with CE and RoHS certifications for all categories. Some of the garden lights and street lamps also have ETL and ENEC certifications.
