The YMLED-6413 series LED streetlights adopt a modular design concept: the image clearly shows two different height versions of the lamp body side-by-side, both featuring a dark gray die-cast aluminum housing with a fine matte finish. The left lamp body has a compact, square column shape; the right lamp body is slightly taller and features a slanted light-emitting surface at the top. Both utilize an integrated heat sink fin structure, maintaining visual consistency while offering flexible options for different installation scenarios.
This series of luminaires strictly adheres to road lighting industry standards. The lamp body is made of 6063-T5 die-cast aluminum, with a surface treated with UV-resistant powder coating. RAL custom colors and enhanced salt spray protection (>1000 hours) are available as options. IP65 dustproof and waterproof rating and IK08 impact resistance ensure long-term stable operation in harsh outdoor environments. Internally, it features high-efficiency LED modules from multiple brands (Philips, CREE, etc. chips that are optional, achieving efficient and uniform road lighting through professional optical design. It supports 2200K-6500K color temperature adjustment and 70/80 high color rendering index options. Wide voltage input (AC 100-277V) and smart control compatibility (DALI/0-10V/PWM/4Di) adapt to global power grid standards, and intelligent road lighting management can be achieved through optional overvoltage protection, sensors, and standardized interfaces (NEMA/Zhaga).
CRI Colour Rendering Index: 70,80(Optional)
LED Chips: Philips5050, CREE XTE, CREE XPG, Ledstar 5050 (selectable)
CCT: 2200K-6500K
RAL finish on request; anti-UV polyester powder coating surface, salt spray resistance over 1,000 hours (optional)
Body Material: Die-cast aluminium,6063-T5
Power supply: AC 100-277 Vac; 50/60 Hz.
Useful life > 50,000h (Ta= 25°C)
Waterproof Protection & Impact Protection Rating: IP65/IK08
Overvoltage protection: 10kV (optional)
Operating temperature: -30°C to +50°C.
Net weight: 8/7.5(kgs)
Available options: DALI, 0-10V, PWM, 4Di.
Optional: 5- to 7-pin NEMA connector, Zhaga, and sensors
| Product Code | Rated Power | LED Qty | Luminous Flux | G.W/N.W | Packing Size |
| YMLED-6413 | 30W | 32 | 3960 | 8/7.5(kgs) | 640x320x100mm |
| YMLED-6413 | 60W | 32 | 7920 | 8/7.5(kgs) | 640x320x100mm |
| YMLED-6413 | 90W | 32 | 11880 | 8/7.5(kgs) | 640x320x100mm |
![]() |
![]() |
![]() |
| Material: PC
Angle: TYPE2
Chip: 5050 3030×4 7070
Size: 50×50
Order Code: 3292
|
Material: PC
Angle: TYPE3
Chip: 5050 3030×4 7070
Size: 50×50
Order Code: 3293
|
Material: PC
Angle: TYPE4
Chip: 5050 3030×4 7070
Size: 50×50
Order Code: 3294
|
![]() |
![]() |
|
| Material: PC
Angle: TYPE5
Chip: 5050 3030×4 7070
Size: 50×50
Order Code: 3295
|
Material: PC
Angle: 100×160
Chip: 5050 3030×4 7070
Size: 50×50
Order Code: 2581
|
RAL finish on request

Samples: Typically 7 working days.
Bulk Orders: Approximately 14-21 working days after receiving the deposit and confirming all specifications.
We accept payments in USD via T/T. The standard terms are:
30% deposit before production, 70% balance before shipment.
For orders below $1000 USD, full payment (100%) is required via T/T.
Our quotations are typically based on EXW or FOB trade terms.
Yes, we offer professional OEM/ODM customization services to meet specific requirements in product design, performance, and packaging.
With extensive experience in non-standard customized products, our engineering team is able to provide technical solutions and initial feedback within 12 hours.
Standard packaging includes brown outer cartons and brown inner boxes.
For orders of any quantity, we offer customization services, including: Laser-engraved logos on the lamp body. Custom-designed color boxes and cartons with your logo.
Considering that most of our customers are involved in engineering projects, we don't have an MOQ.
Our products comply with international standards, with CE and RoHS certifications for all categories. Some of the garden lights and street lamps also have ETL and ENEC certifications.
