The YMLED-6110 garden light, designed specifically for outdoor use, is a lighting solution that combines aesthetics and durability. It features a die-cast 6063-T5 aluminum body with a customizable RAL color for its UV-resistant polyester powder coating. An optional salt spray protection treatment exceeding 1000 hours is also available, ensuring stable performance in various outdoor environments.
This light uses a variety of high-quality LED chips, including Philips 5050, CREE XTE, CREE XPG, and Ledstar 5050. With a color rendering index (CRI) of 70 or 80 and a color temperature range of 2200K-6500K, it can create a warm, inviting atmosphere as well as provide clear, bright cool white light, meeting the lighting needs of different scenarios. Its power supply is compatible with a wide voltage range of AC 100-277 Vac, ensuring stable operation within a temperature range of -30℃ to +50℃. With an IP65 waterproof and dustproof rating and IK08 shock resistance, it easily withstands harsh weather conditions such as rain, snow, and sandstorms, boasting a lifespan of over 50,000 hours.
To adapt to intelligent lighting scenarios, the YMLED-6110 also supports multiple dimming protocols, including DALI, 0-10V, and PWM. It can be equipped with 15- to 7-pin NEMA connectors, Zhaga interfaces, and various sensors for refined lighting management. Whether for private gardens, commercial parks, or municipal landscape projects, its superior performance and flexible configuration make it an ideal choice for outdoor lighting.
CRI Colour Rendering Index: 70,80(Optional)
LED Chips: Philips5050, CREE XTE, CREE XPG, Ledstar 5050
CCT: 2200K-6500K
Body Material: Die-cast aluminium,6063-T5
RAL finish on request; anti-UV polyester powder coating surface, salt spray resistance over 1,000 hours (optional)
Power supply: AC 100-277 Vac; 50/60 Hz.
Useful life > 50,000h (Ta= 25°C)
Waterproof Protection & Impact Protection Rating: IP65/IK08
Overvoltage protection: 10kV (optional)
Operating temperature: -30°C to +50°C
Net weight: 8.4/7.4(kgs)
Available options: DALI, 0-10V, PWM, 4Di.
Optional: 5- to 7-pin NEMA connector, Zhaga, and sensors
| Product Code | Rated Power | LED Qty | Luminous Flux | G.W/N.W | Packing Size |
| YMLED-6110 | 30W | 16 | 3600 | 8.4/7.4(kgs) | 480x425x630mm |
| YMLED-6110 | 40W | 20 | 4800 | 8.4/7.4(kgs) | 480x425x630mm |
| YMLED-6110 | 55W | 24 | 6490 | 8.4/7.4(kgs) | 480x425x630mm |
![]() |
![]() |
![]() |
| Material: PC
Angle: TYPE2
Chip: 5050 3030×4 7070
Size: 50×50
Order Code: 3292
|
Material: PC
Angle: TYPE3
Chip: 5050 3030×4 7070
Size: 50×50
Order Code: 3293
|
Material: PC
Angle: TYPE4
Chip: 5050 3030×4 7070
Size: 50×50
Order Code: 3294
|
![]() |
![]() |
|
| Material: PC
Angle: TYPE5
Chip: 5050 3030×4 7070
Size: 50×50
Order Code: 3295
|
Material: PC
Angle: 100×160
Chip: 5050 3030×4 7070
Size: 50×50
Order Code: 2581
|
RAL finish on request

Samples: Typically 7 working days.
Bulk Orders: Approximately 14-21 working days after receiving the deposit and confirming all specifications.
We accept payments in USD via T/T. The standard terms are:
30% deposit before production, 70% balance before shipment.
For orders below $1000 USD, full payment (100%) is required via T/T.
Our quotations are typically based on EXW or FOB trade terms.
Yes, we offer professional OEM/ODM customization services to meet specific requirements in product design, performance, and packaging.
With extensive experience in non-standard customized products, our engineering team is able to provide technical solutions and initial feedback within 12 hours.
Standard packaging includes brown outer cartons and brown inner boxes.
For orders of any quantity, we offer customization services, including: Laser-engraved logos on the lamp body. Custom-designed color boxes and cartons with your logo.
Considering that most of our customers are involved in engineering projects, we don't have an MOQ.
Our products comply with international standards, with CE and RoHS certifications for all categories. Some of the garden lights and street lamps also have ETL and ENEC certifications.
